主要功能特點：
◆大屏幕液晶顯示，中文(或英文)菜單；
◆采用德國進口紅外線探測器、O2傳感器，不怕震動，穩定性好，精度高；
◆用于測量CO、HC、CO2、O2濃度及 λ值、COcor、轉速、油溫、流量、壓力；
◆具有單怠速、雙怠速、通用測量功能；
◆可測量以汽油、LPG、CNG及酒精等作燃料的車輛；符合最新摩托車GB 14621-2011的測試要求。
◆滿足新國標GB18285-2018及美國BAR－97標準研制，符合ISO3930或OIMLR99  I級精度；
◆具有自動調零，自動清洗，自動溫度補償、壓力補償；
◆具有HC殘留測量、流量監控、氣路泄漏檢查；
◆機內有自我診斷功能，故障時會有提示，直到故障排除方可繼續測量；
◆選配轉速、油溫測量，內置打印機或藍牙、RS232、接口聯網；
◆可車牌號輸入及500組數據存貯，備查功能，時鐘顯示；

主要技術參數：
測量范圍     HC：0～10000×10-6（ppm）vol    CO:0～10×10-2(%)vol
CO2:0～20×10-2(%)vol            O2: 0～25×10-2(%)vol
λ:0.50～3.00                         COcor:0～10×10-2(%)vol
R.M.P  0-9999r.m.p                OIL TEMP:0-150℃
示值誤差     HC±12  ×10-6（ppm）vol(絕對誤差)或±5%(相對誤差)
CO±0.06×10-2(%)vol    (絕對誤差)或±5%(相對誤差)
CO2 ±0.5×10-2(%)vol    (絕對誤差)或±5%(相對誤差)
O2 ±0.1 ×10-2(%)vol    (絕對誤差)或±5%(相對誤差)
重 復 性      重復誤差≤±2%
穩 定 性      自動校零，量矩漂移≤±3%
分 辨 率      HC：1×10-6（ppm）vol    CO: 0.01×10-2(%)vol
CO2: 0.1×10-2(%)vol      O2: 0.01×10-2(%)vol      λ:0.01
R.P.M為10r.p.m,         OIL TEMP為0.1℃
響應時間     95%響應不大于10秒
預熱時間     8min（可預熱3min應急檢測）
輸出方式     可屏幕顯示，可打印氣體濃度最大值、平均值、最小值及車牌號、測試
時間、日期，轉速、油溫和λ、COcor值，可附接口與計算機聯網
環境條件     溫度-5～50℃，相對濕度≤90%
電      源      AC100-240V 50/60Hz 或DC12V（選加電源逆變器）消耗功率40VA
外形尺寸     420mm(長)×310mm(寬)×170mm(高)
重      量      約9kg

Main Features:

◆The large screen liquid crystal display, ( Chinese or English ) menu;

◆The use of German imports of infrared detector, O2 sensor, vibration resistance, good stability, high precision;

◆The measurement of CO, HC, CO2 and O2, COcor, concentration and the lambda value, speed, temperature, flow, pressure;

◆With the single, double idle idle, general measuring function;

◆It can be measured with gasoline, LPG, CNG and alcohol as a fuel for vehicle;

◆According to the new standard and the United States BAR97standards development, in line with the ISO3930or OIMLR99 I level precision;

◆With the automatic zero adjustment, automatic cleaning, automatic temperature compensation, pressure compensation;

◆With the HC residue measurement, traffic monitoring, gas leak check;

◆The machine has self diagnostic function, fault when prompted, until the troubleshooting can continue measurement;

◆With speed, temperature measurement, built-in printer or Bluetooth / RS232 interface ;

◆The license plate number input and 500 groups of data storage, reference function, clock display;

Main technical parameters:

Measuring range:HC: 0~10000×10^-6(ppm)vol,CO: 0~10×10^-2(%)vol )

CO2: 0~20×10^-2(%)vol, O2: 0~25×10^-2(%)vol

R.M.P: 0~9999r.m.p OIL TEMP:0~150℃

Lambda: 0.50~3.00 COcor:0~10×10^-2(%)vol

Indicating error:HC±12×10^-6(ppm)vol ( absolute error ) or±5% ( relative error )

CO±0.06×10^-2(%)vol ( absolute error ) or±5% ( relative error )

CO2±0.5×10^-2(%)vol ( absolute error ) or±5% ( relative error )

O2±0.1×10^-2(%)vol ( absolute error ) or±5% ( relative error )

Stability:moment drift≤±3%

Repeatability ≤±2%

Resolution: HC:1×10^-6(ppm)vol, CO: 0.01×10^-2(%)vol

CO2: 0.1×10^-2(%)vol, O2: 0.01×10^-2(%)vol, Lambda: 0.01

R.P.M:10r.p.m, OIL TEMP:0.1℃

Response time: 95% response is not more than 10 seconds

Preheating time: 8min ( preheating 3min emergency detection )

Output mode can display, print gas concentration maximum value, average value, the minimum

value of the license plate number, test time, date, speed, temperature and COcor value of lambda,

can interface with computer networking

And-use temperature: -5~50°C, Relative humidity: ≤90%

Power: AC100~240V 50/60Hz or DC12V( Add power inverter)

Power consumption: 40VA

Dimension: 420 (L )×310(W)×170(H)mm

Weight: 9kg
